Description
When leaving the marina and heading for the ocean, you depend entirely on your boat’s electrical system. With WhisperPower, you are secured electricity is guided into the appropriate conduits which prevent dangerous situations. The WhisperPower DC distribution program offers high-quality components ensuring a safe and enjoyable trip.
Technical data
| Manufacturer | WhisperPower |
| Article number | 50214731 |
| Dimensions & weight | |
| Weight (Kg) | 0.8 |
| Enclosure width | 95.25 mm |
| Enclosure height | 138.94 mm |
| Enclouser depth | 51.56 mm |
| Input | |
| Battery input | 1 |
| Switch Positions | 2 |
| Manual overide | Locked off/on |
| I 10 Cranking rating 10 sec | 2500A |
| I 60 Cranking rating 1 min | 1100A |
| I 300 Cintermittent rating 5 min | 700A |
| I C continue rating | 500A |
| Vmno Voltage maxium Operation | 32V DC |
| Control Circuit Voltage | 10.1..16.5VDC |
| Operation current continuous | 0 mA |
| Operation current when charging | 7A |
| Remote Control switch when charging | 100mA |
| General | |
| Ambient operation temperature | -20°C ... +40°C |
| Storage temperature | -25oC ... +85oC |
| Operating humidity | 95%, non condens |
| Live current switching | 100.000 cyles |
| Mechanical | |
| Connections terminal stud | M10 (3/8”-.16) |
| Connections stud lenght | 23 mm |
| Maximum terminal Stud Torque | 15.5 NM (140 in-lb) |
| Terminal material | tin-plated copper |
| Drilling mounting centers | 114.3mm * 76.20mm |
| Mounting screws | 4 mm |
| Ingress Protection Class | IP66 |
| Enclouser Colour | RAL9011 Graphite Black |
| Calbe clearance | 28.4 mm (1.12”) |
| Ignition Protection | SA J1171 |
| Markings | CE, Iso 8846 |
Documents: Datasheet
